HP BL685C G6 User Manual
Page 42
Hardware options installation 42
4.
Remove the mezzanine connector cover.
5.
Align the mezzanine connector on the option card with the mezzanine connector on the system
board.
CAUTION:
To prevent damage to the server blade, apply pressure over the mezzanine
connector when installing the mezzanine card. Do not apply pressure to the edges of the card.
6.
Install the mezzanine card. Press down on the connector to seat the card:
o
Mezzanine 1 and 2
