Hardware options installation 31

Hardware options installation

Introduction

If more than one option is being installed, read the installation instructions for all the hardware options
and identify similar steps to streamline the installation process.

WARNING:

To reduce the risk of personal injury from hot surfaces, allow the drives and the

internal system components to cool before touching them.

CAUTION:

To prevent damage to electrical components, properly ground the server before

beginning any installation procedure. Improper grounding can cause electrostatic discharge.

Processor option

The server supports single- and dual-processor operation. With two processors installed, the server
supports boot functions through the processor installed in processor socket 1. However, if processor 1

fails, the system automatically boots from processor 2 and provides a processor failure message.

WARNING:

To reduce the risk of personal injury from hot surfaces, allow the drives and the

internal system components to cool before touching them.

CAUTION:

To avoid damage to the system board:

Do not touch the processor socket contacts.

Always install the processor socket cover after removing the processor from the socket.

Do not tilt or slide the processor when lowering the processor into the socket.

CAUTION:

To avoid damage to the processor:

Handle the processor only by the edges.

Do not touch the bottom of the processor, especially the contact area.

CAUTION:

To prevent possible server blade malfunction and damage to the equipment,

multiprocessor configurations must contain processors with the same part number.

CAUTION:

The server blade supports only two- or four-processor configurations. Always

populate processor sockets 1 and 2 with processors and heatsinks. To prevent overheating,

always populate processor sockets 3 and 4 with processors and heatsinks or processor socket

covers and heatsink blanks.

CAUTION:

The heatsink thermal interface media is not reusable and must be replaced if the

heatsink is removed from the processor after it has been installed.
