English 53
Maint
enanc
e
Removing and reinstalling the oven door
How to remove the door
NOTE
You can remove the upper door the same way you remove the full door.
CAUTION
• The door is very heavy. Be careful when removing and lifting the door. Do not
lift the door by the handle.
• Turn the power OFF before removing the door.
1. Open the door completely.
2. Pull the hinge locks down toward the door frame to the unlocked position.
Locked position
Hinge lock
Unlocked position
Fig. 1 about 5°
Fig. 2
3. Firmly grasp both sides of the door at
the top.
4. Close the door to the door removal
position, which is approximately
5 degrees from vertical (Fig. 1).
5. Lift the door up and out until the hinge
arm is clear of the slot (Fig. 2).
Replacing the oven light
Oven light
The oven light is a standard 40-watt appliance bulb. It comes on when you open
the oven door.
Remove
Glass bulb cover Bulb
Replace
1. Turn off the oven.
2. Make sure the oven and oven light are
cool.
3. Open the door, and remove the glass
cover by turning it counterclockwise.
4. Remove the oven light from the socket
by turning it counterclockwise.
5. Insert a new 40-watt appliance bulb into
the socket, and then turn it clockwise to
tighten.
6. Reinsert the glass cover, and then turn it
clockwise to tighten.
CAUTION
To prevent electric shock, make sure the oven is turned off and cool before
replacing the oven light.
NOTE
• The oven light does not operate during the self-cleaning cycle.
• Remove the racks if they prevent you from accessing the oven light.
