90
4-3-5. IGMP Status
Function name:
IGMP Status
Function description:
Display the IGMP status. In the Fig. 4-29, the window can show VLAN ID for each
multicast group.
Parameter description:
VLAN Id:
Show VLAN Id for each multicast group.
Querier:
Show the group membership queries status.
Queries transmitted:
To count the group membership queries transmitted.
Queries received:
To count the group membership queries received.
V1 Reports:
When a host receives a group membership query, it identifies the groups
associated with the query and determines to which groups it belongs.
The host then sets a timer, with a value less than the Max Response
Time field in the query, for each group it belongs. It calculates the
number of times of IGMP V1 report.
V2 Reports:
When a host receives a group membership query, it identifies the groups
associated with the query and determines to which groups it belongs.
The host then sets a timer, with a value less than the Max Response
Time field in the query, for each group it belongs. It calculates the
number of times of IGMP V2 report.
V3 Reports:
When a host receives a group membership query, it identifies the groups
associated with the query and determines to which groups it belongs.
The host then sets a timer, with a value less than the Max Response
Time field in the query, for each group it belongs. It calculates the
number of times of IGMP V3 report.
V2 Leaves:
When a host leaves a group, it sends a leave group membership
message to multicast routers on the network. It show the leaves number.
