4-2-2. Port Configuration
Function name:
Ports Configuration
Function description:
Ports Configuration is applied to change the settings of each port. In this
configuration function, you can set/reset the following parameters, Mode and
Flow Control. All of them are described in details below.
Parameter description:
Enable Jumbo Frames:
This function supports jumbo frames of up to 9600 bytes, Just tick the
check box (;) to enable it.
Default: disable
Link:
Show link status of this port.
Mode:
Set the speed and duplex of the port. If the media is 1Gbps fiber, there
are three modes to choose: Auto Speed, 1000 Full and Disable. If the
media is TP, the Speed/Duplex is comprised of the combination of speed
mode, 10/100/1000Mbps, and duplex mode, full duplex and half duplex.
The following table summarizes the function the media supports.
Media type NWay Speed Duplex
1000M TP ON/OFF 10/100/1000M Full for all, Half for 10/100
1000M Fiber ON/OFF 1000M Full
In Auto Speed mode, no default value. In Forced mode, default value
depends on your setting.
Flow Control:
You can Just tick the check box (;) to enable flow control. If flow control
is set Enable, both parties can send PAUSE frame to the transmitting
device(s) if the receiving port is too busy to handle. When it is set
Disable, there will be no flow control in the port. It drops the packet if too
much to handle.
Default: Disable
