6
1-5. View of the Optional Modules
Port 21~24 on this switch support two types of media --- TP and SFP Fiber
(LC, BiDi-SC…); this port supports 10/100/1000Mbps TP or 1000Mbps SFP Fiber
with auto-detected function. 1000Mbps SFP Fiber transceiver is used for high-
speed connection expansion; nine optional SFP types provided for the switch are
listed below:
⎯ 1000Mbps LC, MM, SFP Fiber transceiver
⎯ 1000Mbps LC, SM 10km, SFP Fiber transceiver
⎯ 1000Mbps LC, SM 30km, SFP Fiber transceiver
⎯ 1000Mbps LC, SM 50km, SFP Fiber transceiver
⎯ 1000Mbps LC, SM 70km, SFP Fiber transceiver
⎯ 1000Mbps LC, SM 110km, SFP Fiber transceiver
⎯ 1000Mbps BiDi SC, type 1, SM 20km, SFP Fiber WDM transceiver
⎯ 1000Mbps BiDi SC, type 2, SM 20km, SFP Fiber WDM transceiver
⎯ 1000Mbps LC, SM 10km, SFP Fiber transceiver with DDM
Fig. 1-4 Front View of 1000Base-SX/LX LC, SFP Fiber Transceiver
Fig. 1-5 Front View of 1000Base-LX BiDi SC SFP Fiber Transceiver
