4-3-4. RSTP Status
Function name:
RSTP Status
Function description:
Display the RSTP status. In the Fig. 4-28, the window can show the VLAN
bridge information and statuses of 1~24 ports.
Parameter description:
RSTP VLAN Bridge Overview:
VLAN Id:
Show the VLAN Id.
Bridge Id:
Show this switch’s current bridge priority setting and bridge ID
which stands for the MAC address of this switch.
Hello Time:
Show the current hello time of the root bridge. Hello time is a time
interval specified by root bridge, used to request all other bridges
periodically sending hello message every “hello time” seconds to
the bridge attached to its designated port.
Max Age:
Show the root bridge’s current max age time.
Fwd Delay:
Show the root bridge’s forward delay time.
Topology:
Show the root bridge’s spanning tree topology.
Root Id:
Show root bridge ID of this network segment. If this switch is a root
bridge, the “This switch is Root” will show this switch’s bridge ID.
