Panel lock function

To prevent accidental operation of this unit, you can disable operation of

the buttons on the front panel.

INFO

ENTER

X

STATUS

Cursor Up

Cursor Down

Disabling all key button operations

1

Press

X

while you press and hold STATUS and INFO

with the unit in standby mode.

2

Use cursor Up/Down to select “FP/VOL LOCK On”.

3

Press ENTER to enter the setting.

All button operations except

X

are disabled.

Disabling all button operations except

VOLUME

1

Press

X

while you press and hold STATUS and INFO

with the unit in standby mode.

2

Use cursor Up/Down to select “FP LOCK On”.

3

Press ENTER to enter the setting.

All button operations except

X

and VOLUME are disabled.
