169 R5906852 /09 F80
A.4 Specifications of the F80-4K7
Overview
Projector type Single-chip DLP laser phosphor projector
Resolution 3,840 x 2,400 (4K UHD) / 2,716 x 1,600 (WQXGA+ native)
Brightness 7,000 center lumen*
6,600 ansi lumen
7,500 ISO lumen
Contrast ratio 1,200:1 sequential, 10,000:1 dynamic *
Brightness uniformity > 90%
Aspect ratio 16:10
Lens type GLD/FLDX/FLD+(lens adapter needed)
Optical lens shift Vertical up to 125%, depending on lens
Horizontal up to 50%, depending on lens
Motorized zoom and focus (with lens memory on GLD and FLDX lenses)
Motorized lens shift (with position memory on all lenses)
Color space Rec. 709
Color correction P7 RealColor™
CLO (constant light output) Yes
Light source Laser phosphor
Light source lifetime > 20000 h in normal mode, > 12000 h in silent mode, > 40000 h in long life
mode, > 12000 h in high brightness mode
Sealed DLP™ core Yes
Orientation 360° rotation, no restrictions
3D Active stereoscopic 3D / Passive stereo compatible
Image processing Embedded warp & blend engine
Keystone correction Yes
Inputs 12G-SDI, 2x DP 1.2, 2x dual link DVI-D, HDBaseT, HDMI2.0 (HDCP2.2,
HDR10), RJ 45 Ethernet, DMX in/out, RS232 in, 2x USB, 12V out
Input resolutions Up to 4K UHD @ 60Hz / Up to 2,560 x 1,600 @ 120Hz
refresh rates:
24Hz to 120Hz for WQXGA+ (2716x1600) and 24Hz to 60Hz for 4K/
4KUHD (4096 x 2160/ 3860 x 2400)
Software tools Projector Toolset
Control IR, RS232, RJ45, XLR wired
Network connection 10/100 Ethernet, RJ45
Power requirements 100-240V / 50-60Hz
Power consumption 700 W nominal, 850 W maximum
BTU per hour 2,400 BTU/h nominal, 2,900 BTU/h maximum
Specifications
