Bridging
Bridge Statistics
LAN Connection Statistics
Example of LAN
Connection
Statistics Menu
The LAN Connection Statistics Menu screen is shown in Figure 64. Select the
appropriate number to view a particular screen.
Figure 64. LAN Connection Statistics Menu Screen
Example of
Detailed LAN
Connection
Statistics
Figures 65 and 66 show the Detailed LAN Connection Statistics.
Figure 65. Detailed LAN Connection Statistics - First Page
Node:
Address:
Date:
Time:
Menu:Lan Connection Statistics
Path:(Main.5.9)
LAN Connection Stats
LAN Connection Summary Stats
Reset LAN Connection Stats
Node:
Address:
Date:
Time:
Detailed LAN Connection Statistics: LCON-5
Page: 1 of 2
Last Statistics Reset: Date/Time
Transmit Data Summary:
Number of Packets Transmitted:
0
Average Transmit Packet Size:
0
Current Transmit Queue Depth:
0
Maximum Transmit Queue Depth:
0 at Date/Time
Receive Data Summary:
Number of Packets Received :
0
Average Receive Packet Size:
0
Discard Summary:
Transmit Packets Discarded Due to Max Frame Size Exceeded:0
Transmit Packets Discarded Due to Node Transit Delay: 0
Transmit Packets Discarded Due to Congestion:
0
Press any key to continue ( ESC to exit )
