Page 62

Using LANVIEW
5-2 Troubleshooting
Figure 5-1 LANVIEW LEDs for the 2S4082-25
Figure 5-1 LANVIEW LEDs for the 7S4280-19
describes the LED indications and provides recommended actions as appropriate for
both the 2S4082‐25 and 7S4280‐19 modules.
1 MGMT LED
2 Group 1, Port 1 LEDs
1 MGMT LED
2 Group 1, Port 1 LEDs
The terms used in
indicate the following:
• Flashing indicates an LED is flashing randomly.
• Blinking indicates an LED is flashing at a steady rate (approximately 50% on, 50% off).
• Solid indicates a steady LED light. No pulsing.
• Alternating indicates an LED is flashing in a steady rate other than 50% on, 50% off.
