Menu Operation 41
White balance can be adjusted from 2,000 to 11,000 Kelvin (here: 5,600) in steps of 10 K for red/blue
correction. Color compensation for green/magenta tints can be adjusted in a range from -16.0 to +16.0.
Positive or negative CC color compensation values then appear as an exponent of the WB value (here:
+0.0).
Status Section
The status section on the home screen shows key data about recording, power supply, remaining
media capacity and more:
1 3 2
7 6 5
8 4
1 Camera Status 5 Clip Information
2 Codec & Recording Resolution 6 Battery Level
3 Audio Meters 7 Media Capacity & Look Setting
4 Status Icons 8 Camera Alert Icon
Camera Status
STBY
REC
PLAY
ERASE
None Standby - ready for recording.
Recording.
Camera is in play mode.
Erasing the recording media. Active erasing disables recording.
Idle, recording not possible (e.g. no media inserted, media is full).
Codec & Recording Resolution
Currently active codec and recording resolution.
Audio Meters
The audio meters are only displayed if audio recording is enabled and show the current level of audio
channels 1 & 2. If audio recording is disabled, a crossed out speaker icon is displayed.
Black markers are shown at signal levels -20, -18, -9 dBFS for reference test tone. The yellow marker at
-5 dBFS and the red marker at -2 dBFS indicate a signal close to clipping. A red frame around the meter
indicates a clipping at the A/D stage.
Clip Information
REEL
CLIP
DUR Current reel (camera index letter and reel number)
Name of current clip of current reel.
Duration of currently recorded clip (during REC) or last recorded clip (during STBY).
Battery Level
Current battery voltage level.
