Multi Viewfinder MVF-2 37
Headphones Out
The headphones out (18) is a 3.5 mm TRS connector (headphone jack), which outputs all four audio
channels with a maximum power of 2.5 dBm.
NOTICE
Constantly covering the proximity sensor of the MVF-2 can cause an irreversible burn-in on the
viewfinder OLED display. If you need to cover the viewfinder, please disable the EVF OLED first
using the EVF power setting: MENU > Monitoring > EVF/MONITOR > Settings > EVF Power
The Heated Eyecup HE-6 is not compatible with the MVF-2 viewfinder. When using the Heated
Eyecup HE-6, the proximity sensor that activates the OLED display will always be covered. In
this state, the OLED display will not switch off when not in use, this can cause an irreversible
burn-in on the OLED display. Please use the Heated Eyecup HE-7 instead. This is compatible
with the MVF-2 viewfinder.
When shooting in hot environments make sure to have the viewfinder mounted on the viewfinder
bracket to ensure proper cooling.
12.1 Flip-out Monitor
Adjusting the Flip-out Monitor
Fold out, swivel and fold in the monitor to put the display visible in the folded-in position. The image on
the monitor automatically adjusts its orientation, or can be set to the desired orientation in the camera
menu).
Flip-out Monitor
The 4" flip-out monitor with up-and-down tilt function can display the camera live image or the main
user interface (HOME screen and camera menu).
2
3
4
5 1
1 JOGWHEEL 2 HOME / LIVE Button
3 MENU / BACK Button
4 Upper Screen Buttons
5 Lower Screen Buttons
