ARRI ALEXA Mini LF Ready to Shoot V-Mount Set (LPL) - Manual (Page 18)

Camera Layout 18
Camera Rear
1 2
3
4
5
6
7
8
9
1 Boot Status LED
2 POWER Button
3 Camera Status LED
4 Media Door
5 Media Status LED Window
6 WiFi Antenna Connector
7 Fan Outlet
8 White Radio Antenna Connector
9 Rear Connectors
Camera Top
1 2 3
3
1 WiFi Antenna Connector
2 VF Viewfinder Connector
3
Attachment Points for Mechanical Acces-
sories
Camera Bottom
1 2
2
3
4
1 LBUS Connector (on Lens Mount)
2
Attachment Points for Mechanical Acces-
sories
3 Camera ID Label
4 Certification Label
