Fig.: Install Rear Dock
8
Fig.: Install Wireless Adapter
Fig.: Install On - Lap Proprietary HDMI
- A & USB - A to Dock Port Cable
Section 9 Install On - Lap Proprietary HDMI - A & USB - A to Dock
Port Cable
As the fig., remove the rubber bung
at the rear of the monitor firstly.
Insert "On
- Lap Proprietary HDMI - A
& USB - A to Dock Port Cable" to the
rear port of 1102, and then screw it
up. Plug in USB
- A connector to
computer's USB port; HDMI - A con-
nector to computer's HDMI port.
Please press the menu button of
the monitor to enter OSD menu
and choose "HDMI 2" as "Input
Source."
Chapter 3 Hot Keys, LED and OSD Instructions
Section 1 Hot Keys & LED Indications
Notice: If need to adjust “ Increase/up ” or “ Decrease/down ”
continuously , press the button and don't release. Do not press two
buttons at the same time, or it may cause no response or fault response.
Fig.: Install Compute Stick
