34
Other Features
Saving the Unit’s Settings on a USB Flash Drive
You can group together the values in the preset memories
(1 through 8) into a single file and save it to a USB flash drive
connected to the USB MEMORY port.
You can access the saved file (*.X62) on the USB flash drive and
load it into the unit for use when needed.
* When you’re using a USB flash drive for the first time, be sure to
format it on the XS-62S (p. 35).
* Depending on the USB flash drive, recognition of the flash drive
might take some time.
Saving a new settings file
1. Select the [MENU] button 0 “USB MEMORY” 0
“SAVE AS PRESET.”
2. With the cursor positioned at “ENTER,” press the
[VALUE] knob.
The USB SAVE AS screen is displayed.
3. Enter the file name.
Cursor
File name
1. Use the [VALUE] knob to move the cursor.
Moving the cursor to a location where no character is present
increases the number of characters.
2. Press the [VALUE] knob to highlight the character at the cursor
location.
3. Use the [VALUE] knob to change the character, then press the
[VALUE] knob to accept the change.
5 Pressing the [EXIT] button deletes the character at the cursor
location.
5 You can enter a text string of up to 9 characters in length.
5 The extension of the file name is “X62.”
4. When you finish entering the name, use the
[VALUE] knob to select “SAVE,” then press the
[VALUE] knob.
A confirmation message appears.
If you want to cancel the operation, press the [EXIT] button.
5. Use the [VALUE] knob to select “YES,” then press the
[VALUE] knob.
The file (*.X62) is newly saved on the USB flash drive.
6. Press the [MENU] button to quit the menu.
MEMO
Still images (p. 19) are not saved in the file (*.X62).
Overwrite-saving a settings file
1. Select the [MENU] button 0 “USB MEMORY” 0
“SAVE PRESET.”
2. With the cursor positioned at “ENTER,” press the
[VALUE] knob.
The USB SAVE screen is displayed.
3. Select the file to overwrite, then press the [VALUE]
knob.
A confirmation message appears.
If you want to cancel the operation, press the [EXIT] button.
4. Use the [VALUE] knob to select “YES,” then press the
[VALUE] knob.
The file is saved by overwriting.
5. Press the [MENU] button to quit the menu.
Recalling
This loads settings that are in a preset memory (1 through 8)
saved on a USB flash drive. Loading settings overwrites the preset
memory on the unit.
1. Select the [MENU] button 0 “USB MEMORY” 0
“LOAD PRESET.”
2. With the cursor positioned at “ENTER,” press the
[VALUE] knob.
The USB LOAD screen is displayed.
3. Select the file (*.X62) you want to recall, then press
the [VALUE] knob.
A confirmation message appears.
If you want to cancel the operation, press the [EXIT] button.
4. Use the [VALUE] knob to select “YES,” then press the
[VALUE] knob.
The settings are recalled, and the values in the unit’s preset
memories are overwritten.
5. Press the [MENU] button to quit the menu.
