RLX2-IFHxE ♦ Industrial Wireless

Diagnostics and Troubleshooting

Industrial Frequency Hopping Ethernet Radios

User Manual

ProSoft Technology, Inc.

Page 49 of 81

May 28, 2014

3

Diagnostics and Troubleshooting

In This Chapter

Diagnostics Overview ............................................................................ 49

LED Status Indicators ............................................................................ 49

Sources of Interference ......................................................................... 50

Troubleshooting ControlScape FH Error Messages .............................. 53

Troubleshooting Missing Radios ........................................................... 55

RadioLinx OPC Server .......................................................................... 55

3.1

Diagnostics Overview

Use the Diagnostic function in ControlScape FH to:
 View a graphical representation of the overall function of a network.
 Query an individual radio and display its operating parameters.
You can use the information from the diagnostics function to:
 Optimize network function.
 Determine the source of failed communication.

3.2

LED Status Indicators

The RLX2-

IFHxE front panel includes a set of LEDs that indicate the radio’s

status.

After you first plug in the power cable to the radio, the Power/Status LED should
be green, meaning that the radio has power. The RF Transmit and RF Receive
LEDs should blink.

LED

Description

Power

This LED indicates the power and boot status of the radio. Upon application of
power to the radio, the LED lights for about 20 seconds and then begins to flash
slowly for about 30 seconds. The slow flash indicates that the RLX2-IFHE is in
its startup sequence. Once the LED stops flashing and remains lit, the RLX2-
IFHE is ready for normal operation.

Ethernet

If this green LED is lit, the Ethernet cable is connected.
If this LED is flashing, an Ethernet packet is being transmitted or received.

RF Transmit

This yellow LED indicates RF transmission.

Link/RF Receive This green LED indicates RF reception.

232 / 485

On (lit) for RS-232, Off for RS-485/422
