Start Here RLX2-IFHxE ♦ Industrial Wireless
User Manual Industrial Frequency Hopping Ethernet Radios
Page 26 of 81 ProSoft Technology, Inc.
May 28, 2014
2 Connect an Ethernet cable to the ETHERNET port on the bottom of the radio.
o If you are connecting through an Ethernet switch or hub to the radio, use
a straight-through cable to connect the radio to the switch or hub.
o If you are connecting directly from your PC to the radio, use a crossover
cable to connect to the radio from the Ethernet port on your PC.
When the radio is powered up, it goes through a brief self-test during which the
LED Indicators on the front of the radio illuminate. The Power/Status LED should
be green, meaning that the radio has power.
Transferring the Configuration to the Master Radio
To send the new configuration settings to the Master radio, click C ONFIGURE
R ADIO on the Radio Configuration dialog box.
ControlScape FH displays a progress indicator as it attempts to connect to the
radio.
The following message appears when the configuration completes successfully.
