Diagnostics and Troubleshooting
MVI46-DNP ♦ SLC Platform
Master/Slave Communication Module
ProSoft Technology, Inc.
Page 49 of 143
August 23, 2007
Moving Back Through 5 Pages of Registers
Press [-] from the Database View menu to skip back to the previous 500
registers of data.
Viewing the Previous 100 Registers of Data
Press [P] from the Database View menu to display the previous 100 registers of
data.
Skipping 500 Registers of Data
Hold down [Shift] and press [=] to skip forward to the next 500 registers of data.
Viewing the Next 100 Registers of Data
Press [N] from the Database View menu to select and display the next 100
registers of data.
Viewing Data in Decimal Format
Press [D] to display the data on the current page in decimal format.
Viewing Data in Hexadecimal Format
Press [H] to display the data on the current page in hexadecimal format.
Viewing Data in Floating Point Format
Press [F] from the Database View menu. Use this command to display the data
on the current page in floating point format. The program assumes that the
values are aligned on even register boundaries. If floating-point values are not
aligned as such, they are not displayed properly.
Viewing Data in ASCII (Text) Format
Press [A] to display the data on the current page in ASCII format. This is useful
for regions of the database that contain ASCII data.
Viewing Data in Double Word Decimal Format
Press [L] to display the data on the current page in Double Word Decimal format.
This is useful for regions of the database that contain Double Word Decimal data.
Viewing Data in Double Word Decimal Format
Press [X] to display the data on the current page in Double Word Hexadecimal
format. This is useful for regions of the database that contain Double Word
Hexadecimal data.
Viewing DNP Binary Inputs
Press [1] to view a list of DNP Binary Inputs.
