User’s Manual of WGSW-20160HP/WGSW-24040HP series
351
4.18.11 RMON Statistics Detail
This Page provides a Detail of a specific RMON statistics entry; screen in Figure 4-18-11 appears.
Figure 4-18-11: RMON Statistics Detail Page Screenshot
The Page includes the following fields:
Object Description
• Data Source
The port ID which wants to be monitored.
• Drop
The total number of events in which packets were dropped by the probe due to
lack of resources.
• Octets The total number of octets of data (including those in bad packets) received on
the network.
• Pkts
The total number of packets (including bad packets, broadcast packets, and
multicast packets) received.
• Broadcast The total number of good packets received that were directed to the broadcast
address.
• Multicast
The total number of good packets received that were directed to a multicast
address.
• CRC/Alignment
The total number of packets received that had a length (excluding framing bits,
but including FCS octets) of between 64 and 1518 octets.
• Undersize
The total number of packets received that were less than 64 octets.
