Technical Specifications 3-13
Copyright © 2007 by LSI Corporation. All rights reserved.
3.3.1 RAID Controller Specifications
Table 3.6 lists the specifications for the MegaRAID 1078-based SAS
RAID controllers.
Table 3.6 RAID Controller Specifications
Specification
MegaRAID SAS 8704ELP, MegaRAID SAS 8708ELP,
MegaRAID SAS 8708EM2, MegaRAID SAS 8880EM2,
and MegaRAID SAS 8888ELP RAID Controllers
Processor
(PCI Express host
controller to PCI
secondary I/O
controller) LSISAS1078 ROC device with Integrated PowerPC
processor
Part number
• SAS 8704ELP RAID controller: 01116
• SAS 8708ELP RAID controller: 01116
• SAS 8708EM2 RAID controller: 01144
• SAS 8880EM2 RAID controller: 25039
• SAS 8888ELP RAID controller: 01119
• LSIiBBU01 intelligent Battery Backup Unit 01: 01058
• LSIiBBU05 intelligent Battery Backup Unit 05: 01117
• LSIiBBU06 intelligent Battery Backup Unit 05: 29707
• LSIiBBU07 intelligent Battery Backup Unit 05: 31503
• LSIiTBBU03 intelligent Transportable Battery Backup
Unit 03: 01126
Operating voltage +3.3 V, +12 V
Card size
• SAS 8704ELP RAID controller: Low-profile PCI
Express adapter card size (167.64 mm x 68.91 mm)
• SAS 8708ELP RAID controller: Low-profile PCI
Express adapter card size (167.64 mm x 68.91 mm)
• SAS 8708EM2 RAID controller: Low-profile PCI
Express adapter card size (167.64 mm x 68.91 mm)
• SAS 8880EM2 RAID controller: Low-profile PCI
Express adapter card size (167.64 mm x 68.91 mm)
• SAS 8888ELP RAID controller: Extended Length Low-
profile PCI Express adapter card size (167.64 mm x
64.39 mm)
Array interface to the
host PCI Express Rev. 1.0a
