RoamAbout Lightning Protector
A-8
RoamAbout Lightning Protector
The RoamAbout Lightning Protector is a surge arrestor that protects your sensitive
RoamAbout equipment from high-voltage currents caused by discharge and transients at
the antennas.
Table A-7 lists the specifications for the RoamAbout Lightning Protector.
Table A-7: Lightning Protector Specifications
Mechanical
Size
• Height 69 mm (2.7 in.)
• Diameter 26 mm (1 in.)
• Weight 133 g (4.7 oz.)
Connector Type (Access Point 2000)
• FCC Countries Reverse Polarity-N (Male on both ends)
• ETSI Countries: France,
Japan, Asia Pacific Standard-N (Female on both ends)
Connector Type (RoamAbout R2)
• FCC Countries Standard-N (Female on both ends)
• ETSI Countries: France,
Japan, Asia Pacific Standard-N (Female on both ends)
Operating Temperature -40°C to +85°C (-40°F to +185°F)
Electrical
• Frequency Range 800-2500 MHz
• Insertion Loss 0.2 dB
• Surge Current 2000 Amp
• Nominal Impedance 50 Ohms
