1-9
Antenna Options
Antenna Options
The following sections describe the RoamAbout outdoor antennas. Appendix A contains
the specifications for each antenna.
RoamAbout 5 dBi Vehicle-Mount Antenna
The RoamAbout vehicle-mount antenna ( Figure 1-4 ) is a broadband antenna for the 2.4
GHz frequency band featuring an omni-directional pattern with a nominal gain of 5 dBi.
The vehicle-mount antenna can be mounted on vehicles, such as fork-lift trucks, that need
continuous access to network data whether inside or outside of the building.
Figure 1-4: Vehicle-Mount Antenna
Packaged Kit/
Component Component Part Numbers by Domain
FCC ETSI*
VEHICLE-MOUNT
ANTENNA CSIES-AA-MO5 CSIES-AB-MO5
NOTE: The pigtail cable, part number CSIES-**-PT250, used with
the Vehicle Mount Antenna is sold separately.
NOTE
OASP_04G
