Antenna Options
1-10
RoamAbout 14 dBi Directional Antenna
The directional antenna is a totally enclosed 16-element Yagi designed for point-to-point
communications. The antenna is normally mounted on a mast and vertically polarized. The
following sections show the components and part numbers in the RoamAbout directional
antenna kit.
Access Point 2000
Table 1-3 lists the packaged kit components. The numbers in the first column correspond
to the numbers in Figure 1-5 , which shows an example of a RoamAbout Access Point 2000
cabling configuration.
Table 1-3: Access Point 2000 Directional Antenna Component Part Numbers
*European Telecommunications Standards Institute
**128-bit encryption RoamAbout PC Card
# Packaged
Kit/
Component Component Part Numbers by Domain
FCC ETSI* France Asia Pacific
FCC Asia Pacific
ETSI*
OUTDOOR
ANTENNA
KIT CSIED-AA CSIED-AB CSIED-AF CSIED-
AP-FCC CSIED-
AP-ETSI
1 Antenna CSIES-
AA-Y14 CSIES-
AB-Y14 CSIES-
AB-Y14 CSIES-
AB-Y14 CSIES-
AB-Y14
2 50-foot
Cable CSIES-
AA-C50 CSIES-
AB-C50 CSIES-
AB-C50 CSIES-
AB-C50 CSIES-
AB-C50
3 Pigtail
Connection CSIES-
AA-PT50 CSIES-
AB-PT50 CSIES-
AB-PT50 CSIES-
AB-PT50 CSIES-
AB-PT50
4 Access
Point 2000 CSIWS-AA CSIWS-AB CSIWS-AB CSIWS-AB CSIWS-AB
5 PC Card CSIBD-
AA-128** CSILD-AB CSILD-AF CSIBD-AA CSIBD-AB
6 Lightning
Protector CSIES-
AA-LP CSIES-
AB-LP CSIES-
AB-LP CSIES-
AB-LP CSIES-
AB-LP
NOTE: An optional 75-foot cable, part number CSIES-AA-C75 or
CSIES-AB-C75, not included in the kit is also available. Contact your
Enterasys Networks Representative for more information.
