Antenna Options
Figure 1-5: Yagi Antenna Configuration Example (AP 2000)
Low-Loss
Cable (2)
Lightning
Protector (6)
Pigtail
Connection (3)
www
.cable
tron.c
om/w
ireles
s
To Power Outlet
Insert Ethernet
Cable from
Network
Remote Power
Adapter
PC Card (5)
Antenna
Cable
Antenna (1)
Access Point (4)
Ear
th Ground (Outdoors)
Ground
Ground
Ear
th Ground (Outdoors)
Ensure both Earth Ground
Connections are connected
to the same Earth Ground
using an equipotential
bonding conductor.
INDOOR
OUTDOOR
