Antenna Options

1-14

RoamAbout 7 dBi Omni-Directional Antenna

The RoamAbout omni-directional antenna is a broadband antenna for the 2.4 GHz
frequency band featuring an omni-directional pattern with a nominal gain of 7 dBi.

This antenna is encapsulated in a weatherproof protective covering. With the hardware
provided, this vertically-polarized antenna can be mounted on an antenna mast with an
outside diameter of up to 51mm (2 in.).

Access Point 2000

Table 1-5

lists the antenna and related components with their part numbers. The numbers

in the first column correspond to the numbers in

Figure 1-7

, which shows an example of a

RoamAbout Access Point 2000 cabling configuration.

Table 1-5: Omni-Directional Component Part Numbers (Access Point 2000)

*

European Telecommunications Standards Institute

**

128-bit encryption RoamAbout PC Card

#

Packaged
Kit/
Component

Component Part Numbers by Domain

FCC

ETSI* and
Asia Pacific ETSI*

France

Asia Pacific FCC

OUTDOOR
ANTENNA
KIT

CSIED-AA-M07 CSIED-AB-M07

CSIED-AF-M07 CSIED-APFCCM7

1

Antenna

CSIES-AA-M07

CSIES-AB-M07

CSIES-AB-M07

CSIES-AB-M07

2

50-foot
Cable

CSIES-AA-C50

CSIES-AB-C50

CSIES-AB-C50

CSIES-AB-C50

3

Pigtail
Connection

CSIES-AA-PT50

CSIES-AB-PT50

CSIES-AB-PT50

CSIES-AB-PT50

4

Access Point
2000

CSIWS-AA

CSIWS-AB

CSIWS-AB

CSIWS-AB

5

PC Card

CSIBD-AA-128**

CSIBD-AB

CSIBD-AF

CSIBD-AA

6

Lightning
Protector

CSIES-AA-LP

CSIES-AB-LP

CSIES-AB-LP

CSIES-AB-LP

NOTE: An optional 75-foot cable, part number CSIES-AA-C75 or
CSIES-AB-C75, not included in the kit is also available. Contact your
Enterasys Networks Representative for more information.
