A-1
Appendix A
Specifications
This appendix lists the specifications of the various RoamAbout outdoor antenna products.
RoamAbout 14 dBi Directional Antenna
The directional antenna is a totally enclosed 16-element Yagi designed for point-to-point
communications. The antenna is normally mounted on a mast and vertically polarized.
Table A-1: 14 dBi Directional Antenna Specifications
Mechanical
• Size 45.7 cm (18 in.)
• Mounting Method • Vertical mast with an outside diameter between 35
mm (1.4 in.) and 42 mm (1.6 in.) using u-bolts.
• Wall using plugs and screws.
Cable
• Type RG-58A/U, 50 ohm low-loss coax
• Length 31 1/4 in. (+/- 1 in.)
• Color White
Connector Type (Access Point 2000)
• FCC Countries Reverse Polarity-N (Male)
• ETSI Countries:
France, Japan,
Asia Pacific Standard-N (Female)
Connector Type (RoamAbout R2)
• FCC Countries Standard-N (Female)
• ETSI Countries:
France, Japan,
Asia Pacific Standard-N (Female)
