A-7
Low-Loss Antenna Cable
Table A-6: Cable Specifications for the 22 Meter (75 Foot) Antenna
Mechanical Specifications
• Length 22 meter (75 ft)
• Diameter 10 mm (0.4 in.)
• Weight 101.2 gram/meter (0.068 lbs/ft)
• Bend Radius 25 mm (1 in.)
Connector Type (Access Point 2000)
• FCC Countries Reverse Polarity-N (Female on both ends)
• ETSI Countries: France,
Japan, Asia Pacific Standard-N (Male on both ends)
Connector Type (RoamAbout R2)
• FCC Countries Standard-N (Male on both ends)
• ETSI Countries: France,
Japan, Asia Pacific Standard-N (Male on both ends)
Operating Temperature -40°C to +85°C (-40°F to +185°F)
Electrical Specifications
• Insertion Loss 0.22 dB/meter (6.8 dB/100 feet)
• Total for this cable 5.1 dB
