Condition Data-Block
Order of
bytes
Data
(in hex)
Contents
Explanation
(Information block)
1
02
STX code
Header: indicates the beginning of
the data-block
2
xx*
Status
Status byte: indicates the status of
the scanner
3
23
35 Bytes
Byte counter: indicates the number
of bytes of data
4
00
(Data)
1
43
‘‘C’’
Color mode
2
xx
0
3
52
‘‘R’’
Resolution
4
xx
n1
(main scan resolution)
5
xx
6
xx
n2
(sub scan resolution)
7
xx
8
41
‘‘A’’
Reading area
(main scan offset length)
(sub scan offset length)
(main scan read length)
(sub scan read length)
9
xx
n1
10
xx
11
xx
n2
12
xx
13
xx
n3
14
xx
15
xx
n4
16
xx
17
44
‘‘D’’
Data format
18
xx
i
19
42
‘‘B’’
Halftoning mode
20
xx
i
21
4C
‘‘L’’
Brightness
22
xx
i
23
5A
‘‘Z’’
Gamma correction
24
xx
i
25
48
‘‘H’’
Zoom
