Order of
bytes Data
(in hex) Contents Explanation
81 52 ‘‘R’’ Available resolution
(1200 dpi)
82 B0 1200
83 04
84 41 ‘‘A’’ Maximum reading area at the
maximum resolution and 100%
zoom
(main scan 10200 dots by sub
scan 14040 dots)
85 D8 10200
86 27
87 98 14040
88 3A
*(xx denotes a variable)
The Condition Data-Block
The GT-5000 sends the following data-block when it receives the
ESC S (Request condition) command.
Condition Data-Block
Order of
bytes Data
(in hex) Contents Explanation
(Information block)
1 02 STX code Header: indicates the beginning of
the data-block
2 xx* Status Status byte: indicates the status of
the scanner
3 23 35 Bytes Byte counter: indicates the number
of bytes of data
4 00
(Data)
1 43 ‘‘C’’ Color mode
2 xx i
3 52 ‘‘R’’ Resolution
4 xx n1 (main scan resolution)
5 xx
6 xx n2 (sub scan resolution)
7 xx
Scanner Model Technical Data B-75
