Specifications and Regulatory Information Page 88
Software and Firmware Specifications
Installation Features
• Easy access to configuration pages via a web browser
• Auto detection of common problems (connection not possible, incorrect configuration, etc.)
Administration Features
• Web-based interface (accessed via a web browser)
• Command line interface (accessed via Telnet)
• File configuration (accessed via TFTP)
• Diva Assistant (Windows only) accessible from system tray
• Password protection (Web and CLI)
• Simple firmware upgrade procedure (via Web, CLI, and Diva Assistant)
• Configuration update and backup to local drive (via web, CLI, and Diva Assistant)
ADSL Features
• Full-rate (G.992.1 and T1.413 Issue 2), providing a maximum of 8 Mbps downstream and 820
Kbps upstream (can be used with or without a splitter)
• G.Lite (G.992.2), providing a maximum of 1.5 Mbps downstream and 512 Kbps upstream
(can be used with or without a splitter)
• Splitterless operation may require the use of microfilters for analog devices using the same
wiring as the ADSL modem
• G.994.1 (G.hs) (DSL handshaking)
• ANSI T1.413 Issue 2 compliant
• Interleaved and fast-path ADSL channels
• Interoperable with ITU and ANSI standards-based DSLAM
IP Services
• IP, IP over Ethernet, IP over IEEE 802 Networks
• DHCP server
• TFTP client and server
• Telnet server
• HTTP server
Security
• IP Filtering
• Ethernet Filtering
• Password protection
ATM Features
• AAL5 (ATM Adaptation Layer 5)
• VC Multiplexed
• LLC Encapsulation
• UNI 3.0, 3.1
• F4/F5 OAM Cells (ATM Loopback)
• Precise Peak Cell Rate Traffic Shaping on a per VC basis
• Up to 8 active VCs
• VPI Address Range 0-255
• VCI Address Range 0-65535
• UBR/CBR
