Advanced Topics Page 58
Using TFTP to Transfer Files
The TFTP interface lets you upload and download configuration files and firmware. However, it
is often easier to use the web or command line interface to do most TFTP tasks.
Prerequisites
• The TFTP interface requires TFTP client software. A shareware client is included on the Diva
CD-ROM.
• Connection via an Ethernet or USB port (except when device is in boot or fault mode).
• Support for TFTP server must be enabled via command line interface.
Enabling TFTP server support
TFTP is disabled by default. To enable TFTP support, log into the CLI (see Command Line
Interface (CLI) on page 56) and enter the following commands.
enable tftp server
save
Uploading/downloading configuration files
All configuration settings on the Diva 2440 are stored in configuration files.
Using TFTP, you can access these files to retrieve and set configuration values.
File Name Access Mode Port Description
image.eim Write Boot /
Normal USB /
Ethernet Contains the Diva 2440 firmware.
Write to this file to update the
firmware. After writing is complete, a
reset is automatically performed.
message.txt Read-only Boot Ethernet Description of why boot monitor mode
was entered. You are in boot monitor
mode if the Power status indicator is
alternating between red and green.
You can enter boot monitor mode by
holding down the Reset button for
more than 5 seconds but less than 15
seconds. To exit boot monitor mode,
press the Reset button once.
dump.dmc Read-only Boot Ethernet A file containing a memory dump. This
is used for troubleshooting purposes.
config.bat Write-only Normal USB /
Ethernet
A file containing CLI commands. The
commands in this file are
automatically executed after being
uploaded with TFTP. Trace commands
are not supported by this file.
trace.bat Write-only Same as config.bat except that it
supports trace commands.
result.txt Read-only Normal USB /
Ethernet
Contains the results of the last .bat file
that was executed.
