System Application Guide SAG582135000
Spec. No. 582135000 (Model LXP48F1) Issue AE, January 31, 2007
Page 35 of 43
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
PHYSICAL SIZE INFORMATION
Distribution Cabinet Dimensions—Lists BD, BL, BS, LB, LD, LS, LX
Note: For overall dimensions of List 1 Power Shelves, refer to SAG589200100.
LEFT SIDE VIEW
RIGHT SIDE VIEW
TOP VIEW
FRONT VIEW
MOUNTING ANGLE DETAIL
0.250 x 0.375
SLOT
0.750
0.750
1.250
0.234
0.234
5.250
23.000
21.380
22.250
12.000
5.000
See Mounting Angle Detail
NOTES :
1.
2. Weight of Distribution
Cabinet with Circuit Breakers
(In Pounds):
3. Finish :
All dimensions are in inches.
Shelf Body: Bright Zinc
Front Panel: Textured Warm
Gray (M500-146)
Net: 33
Shipping:
0.500
0.500
0.500
0.500
