System Application Guide
SAG582135000
Spec. No. 582135000 (Model LXP48F1)
Issue AE, January 31, 2007
Page 25 of 43
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
5
Wire Size / Loop Length Combination Calculated using 65°C Ambient Operating Temperature.
6
Load lugs are one-hole for 1/4" bolt clearance. Load Return lugs are two-hole for 1/4" bolt
clearance on 5/8" centers. Refer to drawing 031110100 for lug crimping information.
Distribution (Load) Wire Sizes and Lugs—List GA
Features
♦ In each List GA Distribution Cabinet, Screw compression terminals are provided for connecting Load and
Load Return wiring. Maximum size of wire to be connected to a single position is 14 AWG.
Battery Wire Sizes and Lugs—All Lists
Features
♦ List BD, BL, BS, LB, LD, LS, LX: In each Distribution Cabinet, lug-terminated battery conductors are
connected to the battery terminals. Captive nuts, (1/4-20 on 5/8" centers) are provided for installation of
customer provided two-hole lugs.
List GA: In each Distribution Cabinet, lug-terminated battery conductors are connected to the battery
terminals. Captive nuts, (1/4-20 on 5/8" centers) are provided for installation of customer provided two-hole
lugs.
♦ For lug mounting hole size and spacing dimensions, refer to the illustration provided in the
Restrictions
All lugs for customer connections must be ordered separately.
Customer must supply lug-mounting hardware.
Ordering Notes
1) Battery wire size varies depending on load, therefore no specific information is provided for wire size.
for recommended wire sizes and lugs at rated maximum Distribution Cabinet load.
When making connections, observe correct polarity.
2) For other available lugs and hardware, refer to drawings 031110100 through 031110300.
