Alarm-Type Fuses
Note: When used for power distribution, load should not exceed 80% of device rating.
BUSSMANN ALARM-TYPE FUSES
AMPERE RATING
PART NUMBER
FUSE
COLOR
18/100 GMT-A
248610301
---
1/4 248610200
VIOLET
1/2 248610300 RED
3/4 248610500
BROWN
1-1/3 248610700
WHITE
2 248610800
ORANGE
3 248610900
BLUE
5 248611000
GREEN
7-1/2 248611300
BLACK-WHITE
10 248611200
RED-WHITE
15 248611500
RED-BLUE
Fuse Safety Cover
(Replacement)
248898700 ---
Dummy Fuse
(Replacement)
248872600 ---
Table 3
