Overview
Fast Network 10 User Guide Page 1-5
.
Figure 1-1 FN10 Front Panels
Figure 1-2 FN10 Rear Panel with the Optional Fast Ethernet Ports
The FN10:
• Provides dedicated bandwidth for each network connected to its ports.
• Provides full store and forward bridging functionality.
• Provides complete error checking functionality.
• Provides port trunking to increase bandwidth.
• Allows you to define virtual workgroups to optimize network traffic.
• Filters and forwards received Ethernet packets based on Network
Management System (NMS) configurable parameters.
• Supports 48-bit IEEE 802 MAC addressing.
Front Panel with 12 10BASE-T (10 Mbps) Ports
Front Panel with 24 10BASE-T (10 Mbps) Ports
X 2X 3X 4X 5X 6X 7X 8X 9X 10X 11X 12X AUI 1
Link
2 3 1 4 5 6 7 8 9 10 11 12 A B Usr
Segment Status
Select
TX
RX
Act
Col
Reset Ready
FN10-12
NMS Port Pwr
X 2X 3X 4X 5X 6X 7X 8X 9X 10X 11X 12X
13X 14X 15X 16X 17X 18X 19X 20X 21X 22X 23X 24X 13 14 15 16 17 18 19 20 21 22 23 24
AUI 1
Link
Link
2 3 1 4 5 6 7 8 9 10 11 12 A B Usr
Segment Status
Select
TX
RX
Act
Col
Reset Ready
NMS Port Pwr
FN10-24
Rear Panel with 2 Fast Ethernet (100 Mbps) Ports
Port B Port A Link
Status
Ready
Port B Port A
Link LinkStatus Status Ready
B A
RX TX RX TX
RJ45
ST fiber-optic
Connection type options
