48 © 2012 Magnum Energy, Inc.
4.0 Menu Map
TECH
continued….
Read Only display
04 Fault History
Press SELECT
03 Inv Model
MSH4024RE
Set SETUP
PIN = 0000
Set SETUP
Unlock SETUP
Set SETUP
Lock SETUP
06 Ext Control
###
07 Load Defaults
Press SELECT
07 Load Defaults
Defaults in #.#
07 Load Defaults
DEFAULTS LOADED
Factory Defaults
Loaded
06 Ext Control
Press SELECT
06 Ext Control
No Ext Control
05 SETUP PIN
SETUP Unlocked
Set SETUP
Change PIN
S
S
S
S
Read Only displays
S
Read Only display
04A Inv Faults
Press SELECT
Fault.. *
H1 FETs: ###F
Range: H1 to H9, Day since, Time, Status, VDC, ADC,
BTS Temp, Transformer Temp, Transistor (FETs) Temp
Fault.. *
H1 Status..
S
Fault.. *
H1 Tfmer: ###F
Fault.. *
H1 BTS: ###F
Fault.. *
H1 D- 0 HH:MM
Fault.. *
H1 VDC DCA
Refer to the AGS TECH menu maps (see Figure 7-3)
04B AGS Faults
Press SELECT
04C Clear Faults
Press SELECT
04C Clear Faults
HISTORY CLEARED
S
04C Clear Faults
Clearing in #.#
Press and hold SELECT
button for 5 seconds
LEGEND
Menu Selections
Menu Button
Default/Current
Setting
Change Settings
Menu Heading
Set Search Watts
5 Watts
SETUP
S
Press button
Press SELECT
02A Search Watts
5 Watts
*Specific fault is listed; if no fault,
“No Error Record” displays
= current setting*
* For this menu map, the arrow denotes the factory default setting
If “Yes”, only a 3-digit
number displays
Press and hold SELECT button
for 5 seconds
Figure 4-5, TECH Button Menu Map
