SMA Technology AG Technical data
Operating instructions WB50_60-11:FE4105 Page 49
9 Technical data
9.1 Windy Boy 5000
9.1.1 DC connection data
Max. input open circuit voltage V
DC 0
600 V
Input voltage, MPP range V
DC
246 V ... 600 V DC
Nominal DC operating voltage V
DC nom
270 V
Max. input current I
DC max
26 A
Max. input power P
DC max
5750 W
Recommended generator power
at 5,000 full-load hours / year P
turb max
4000 W
Recommended generator power
at 2,500 full-load hours / year P
turb max
4500 W
All-pole isolator on the DC input
side DC plug connector
Overvoltage protection Thermally monitored varistors
DC voltage ripple U
SS
< 10% of the input voltage
Personal protection Insulation monitoring (Riso > 1 MΩ)
Own consumption in standby
mode < 7 W (standby)
Reverse polarity protection Short circuit diode
