UPS Specifications
40
6.4.1 Battery Manufacturers and Models
Either of two manufacturers’ batteries will be installed in the NX 10-30 kVA 208V as shipped. Below
are the battery makers and the models they supply.
6.4.2 Input Rectifier
6.4.3 DC Intermediate Circuit
Table 11
Approved batteries
Battery Manufacturer
Models Supplied
Enersys Yuasa
NPX-80FR
NPX-100FR
NPX-150FR
C&D Dynasty
UPS12-100MR
UPS12-140MR
-
Table 12
Rectifier input power
Rated Power
10kVA
15kVA
20kVA
30kVA
Rated Voltage, VAC
120/208
Supply
3-phase, 4-wire plus ground
Input Voltage Tolerance, VAC (without derating)
166-239
Frequency, Hz
50 / 60
Input Frequency Tolerance %
±10
Power Factor
≤ 0.99 at full load
≤ 0.95 at 50% load
Harmonic Current
Less than 4% at full rated UPS output load
Input Current,
1
Nominal, A
28
42
56
83
Output Current, Nominal, A
28
42
56
83
Notes:
1. Overload capacity of input current:
100% Imax I>150%: 10 min. Table 13 DC intermediate circuit Rated Power 10kVA 15kVA 20kVA 30kVA Recommended number of lead-acid batteries Number of batteries is 24 jars (12V per jar), or 144 cells (2V per cell) for VRLA. The unit is shipped with a nominal voltage of 288VDC. Recommended float charge voltage 2.27VDC* Recommended boost charge voltage 2.3VDC* Recommended end of discharge voltage 1.65-1.8 VDC Maximum recharge battery current, A 7.5 7.5 15 15 Maximum boost charge duration, min.* 1440 Boost-float threshold current, A* 0.1 C default Temperature voltage compensation, mV/°C* 3 Ripple voltage superimposed % ≤ 1 * Set by configuration software and based on usage of VLRA batteries.
1 min.
Limits input current immediately
