420 MOD Functions
16.5 Ether
n
et Int
e
rf
ace
Use the ping function to check whether a connection
to a particular remote station in the network is
available. The address is entered as four decimal
numbers separated by points (dotted-decimal
notation).
The TNC displays an overview window with
information on the active network connections.
Configure the access to network drives. (Selectable
only after entry of the MOD code number NET123)
Open the dialog window for editing the data of an
existing network connection. (Selectable only after
entry of the MOD code number NET123)
Configure the network address of the control.
(Selectable only after entry of the MOD code number
NET123)
Delete an existing network connection. (Selectable
only after entry of the MOD code number NET123)
Function Soft key
