HEIDENHAIN TNC 620 219
8.7 A
d
ditional F
unctions
Data from the tool table, 50 1 Tool no. Tool length
2 Tool no. Tool radius
3 Tool no. Tool radius R2
4 Tool no. Tool length oversize DL
5 Tool no. Tool radius oversize DR
6 Tool no. Tool radius oversize DR2
7 Tool no. Tool inhibited (0 or 1)
8 Tool no. Number of the replacement tool
9 Tool no. Maximum tool age TIME1
10 Tool no. Maximum tool age TIME2
11 Tool no. Current tool age CUR. TIME
12 Tool no. PLC status
13 Tool no. Maximum tooth length LCUTS
14 Tool no. Maximum plunge angle ANGLE
15 Tool no. TT: Number of teeth CUT
16 Tool no. TT: Wear tolerance for length LTOL
17 Tool no. TT: Wear tolerance for radius RTOL
18 Tool no. TT: Rotational direction DIRECT
(0=positive/-1=negative)
19 Tool no. TT: Offset in plane R-OFFS
20 Tool no. TT: Offset in length L-OFFS
21 Tool no. TT: Break tolerance for length LBREAK
22 Tool no. TT: Break tolerance for radius RBREAK
23 Tool no. PLC value
24 Tool no. Probe-center offset in reference axis CAL-OF1
25 Tool no. Probe-center offset in minor axis CAL-OF2
26 Tool no. Spindle angle for calibration CAL-ANG
27 Tool no. Tool type for pocket table
28 Tool no. Maximum rpm NMAX
Group name, ID no. Number Index Meaning
