HEIDENHAIN TNC 620 511
Graphic support
„ 2-D programming graphics „ X „ X
„ Synchronization between block display and graphics „ – „ X
„ REDRAW function „ – „ X
„ Show grid lines as the background „ X „ –
„ 3-D programming graphics „ – „ X
„ Test graphics (plan view, projection in 3 planes, 3-D view) „ X „ X
„ High-resolution view „ – „ X
„ Image data processing „ Blockwise „ Continual
„ Tool display „ X „ X
„ Set the simulation speed „ X „ X
„ Coordinates of line intersection for projection in 3 planes „ – „ X
„ Expanded zoom functions (mouse operation) „ X „ X
„ Displaying frame for workpiece blank „ X „ X
„ Displaying the depth value in plan view during mouse-over „ – „ X
„ Targeted stop of test run (STOP AT N) „ – „ X
„ Consideration of tool change macro „ – „ X
„ Program run graphics (plan view, projection in 3 planes, 3-D view) „ X „ X
„ High-resolution view „ – „ X
„ Saving/opening of simulation results „ – „ –
Datum tables: for storing workpiece-related datums X X
Preset table: for saving reference points (presets) X X
Pallet management
„ Support of pallet files „ X „ X
„ Tool-oriented machining „ – „ X
„ Pallet preset table: for managing pallet datums „ – „ X
Returning to the contour
„ With mid-program startup „ X „ X
„ After program interruption „ X „ X
Autostart function X X
Actual position capture: Actual positions can be transferred to the
NC program X X
Enhanced file management
„ Creating multiple directories and subdirectories „ X „ X
„ Sorting function „ X „ X
„ Mouse operation „ X „ X
„ Selection of target directory by soft key „ X „ X
Function TNC 620 iTNC 530
