HEIDENHAIN TNC 620 259
8.8 A
d
ditional F
unctions
3 1 to 9
(X, Y, Z, A, B, C, U, V,
W) Result of measurement of the touch probe cycles
0 and 1 without probe radius or probe length
compensation
4 1 to 9
(X, Y, Z, A, B, C, U, V,
W) Last reference point of a manual touch probe
cycle, or last touch point from Cycle 0 without
probe length or stylus probe compensation
(workpiece coordinate system)
10 - Oriented spindle stop
Value from the active datum table
in the active coordinate system,
500 Line Column Read values
Basic transformation, 507 Line 1 to 6
(X, Y, Z, SPA, SPB, SPC) Read the basic transformation of a preset
Axis offset, 508 Line 1 to 9
(X_OFFS, Y_OFFS,
Z_OFFS, A_OFFS,
B_OFFS, C_OFFS,
U_OFFS, V_OFFS,
W_OFFS) Read the axis offset of a preset
Active preset, 530 1 - Read the number of the active preset
Read data of the current tool, 950 1 - Tool length L
2 - Tool radius R
3 - Tool radius R2
4 - Tool length oversize DL
5 - Tool radius oversize DR
6 - Tool radius oversize DR2
7 - Tool locked TL
0 = not locked, 1 = locked
8 - Number of the replacement tool RT
9 - Maximum tool age TIME1
10 - Maximum tool age TIME2
11 - Current tool age CUR. TIME
12 - PLC status
13 - Maximum tooth length LCUTS
14 - Maximum plunge angle ANGLE
15 - TT: Number of teeth CUT
Group name, ID no. Number Index Meaning
