HEIDENHAIN iTNC 530 179
5.2 T
ool D
a
ta
DR2TABLE 3D ToolComp software option: Enter the name of the
compensation value table from which the TNC is to take the
angle-dependent delta radius values DR2 (see also ”3-D tool radius
compensation depending on the tool’s contact angle (3D-
ToolComp software option)” on page 515) Compensation-value table?
LAST_USE Date and time at which the TNC inserted the tool for the last time
via TOOL CALL.
Input range: 16 characters max., format internally specified: Date
= yyyy.mm.dd, time = hh.mm
Date/time of last tool call?
Abbr. Inputs Dialog
