35
b: Parameters:
Parameter settings can be changed by entering a value
(e.g.: CORRECT.LIN. 13.600 etc.)
P 1 8 L . C L A S S . = + 1 2 0 . 0 0 0 0
15 characters 3 char. 13 characters 2 characters
P 4 1 L . C O M P . = - 1 4 0 0 . 0
15 characters 3 char. 13 characters 2 characters
Parameter designation Text Separator Parameter value End of line
left-justified right-justified block right-justified
Last line:
Each parameter list ends with the final character <*> (HEX: 0x2A)
*
The parameter text is sent in the language you have set and corresponds to the dialog text that is shown on the display unit.
The parameter value, not the text, is definitive when the parameters are transferred to the display unit. Output Format of the Parameter List
