v2.0
LDK 8000 User’s Guide | Menu structure and contents 6-18
6.2.7 Diagnostics menu contents
MENU VALUES DESCRIPTION LEVEL FILE
Adaptor Type Triax, DVCPRO, ... Displays value 2
Sensor Type IT, ITW, FT, DPM Displays value 2
Sensor Voltage Ok, NotOK Displays value 2
Shutter Run Run, Stop Displays value 2
Front Power Ok, NotOk Displays value 2
Camera 12nc last 4 digits of type no. Displays value 2
Camera Status 2 digits Displays value 2
Adapter 12nc last 4 digits of type no. Displays value 2
Adapter Status 2 digits Displays value 2
PPG Status 0..255 Displays value 0
DVP Status 0..255 Displays value 0
Cam. temp Displays value 0
Head temp C -55..128 Displays value 0
Head temp F -67..262 Displays value 0
Head fan Off, Low, Mid, High, Max Displays value 0
Adaptor temp C -55..128 Displays value 0
Adaptor temp F -67..262 Displays value 0
Adaptor fan Off, Low, Mid, High, Max Displays value 0
