v2.0
LDK 8000 User’s Guide | Operating instructions 5-6
5.4 Video acquisition modes
In the INSTALL menu choose the video mode you wish to use for acquisition. The table below
shows the output signals available for each mode.
5.4.1 Standard camera version
Zoom
Switch on external signal 1
Switch on external signal 2
Zoom switch Momentary
Alternating (latched)
Switch Assignments for Triax operation
Acquisition format
(sensor) HDTV
output (B.S.) SDTV
output (B.S.) Camera HD-SDI
output Viewfinder
indication
1080i at 59.94 Hz 1080i59.94 525i59.94 (NTSC) A: 1080i59.94
B: VF signal (1080i59.94) 1080i59
1080i at 50 Hz 1080i50 626i50 (PAL) A: 1080i50
B: VF signal (1080i50) 1080i50
720p at 59.94 Hz 720p59.94 525i59.94 (NTSC) A: 720p59.94
B: VF signal (720p59.94) 720p59
720p at 50 Hz 720p50 626i50 (PAL) A: 720p50
B: VF signal (720p50) 720p50
