LDK 8000 User’s Guide | Operating instructions 5-21
3. Press the Select button. The following appears in the viewfinder.
4. Point two small white boxes at the intended surface.
5. Press the Select button to start the measurement procedure (the iris is set to Auto). The
process running message appears:
6. When the process is completed (within a few seconds) the OK message appears in the
viewfinder.
7. Adjust the skin contour level with the VIDEO\SKIN\SKIN LEVEL item. Decrease the
value below 50 to soften the selected area. Increase the value above 50 to add extra
contour.
Repeat the steps for the other memory position if required. Both skin contour settings can be
used at the same time. Set the menu item
VIDEO\SKIN\VIEW to on to indicate the effected
area.
ND/RE BATT TAPE REC ++ + -
! AW2 AW1 FL 7.5 5.6 3.2
ASKIN: window
ND/RE BATT TAPE REC ++ + -
! AW2 AW1 FL 7.5 5.6 3.2
ASKIN: running
