2 multiple triaxhd cameras with c2ip network – Grass Valley LDK 8000 v.2.0 User Manual
Page 30
v2.0
LDK 8000 User’s Guide | Configurations
3-2
3.2
Multiple TriaxHD cameras with C2IP network
The Base Stations are each connected to a network hub or router via an Ethernet cable
(straight through, not cross-over). The OCP 400 operational control panels and, if required the
MCP 400 Master Control Panel, are also connected to the Ethernet network via a hub or
router.
Figure 3-2. Multiple HD cameras with C2IP network control
Camera Base Station
Camera Base Station
Camera Base Station
Camera head
Triax adapter
Base Station
Triax cable
Ethernet cable
Hub or switch
Hub or switch
MCP 400
Ethernet cable
