LDK 8000 User’s Guide | Installation

2-9

2.8

Adjusting the shoulder pad

To change the position the shoulder pad press and hold lever (1). The shoulder pad can now be
moved backwards and forwards along the axis of the camera. Adjust the shoulder pad when all
units have been mounted to get the best balanced shoulder position.

Figure 2-9. Shoulder pad

1
